Iron Toxicity Tolerance of Rice Genotypes in Relation to Growth, Yield and Physiochemical Characters

doi:10.1016/j.rsci.2023.02.002

Abstract

Abstract:

Iron (Fe) toxicity, generated from excess reduced ferrous Fe (Fe²⁺) ion formation within the soil under submerged condition, is a potent environmental stress that limits lowland rice production. Total 11 diverse Thai rice genotypes, including a recognized tolerant genotype Azucena and a susceptible genotype IR64, were evaluated against 5 Fe²⁺ levels [0 (control), 150, 300, 600 and 900 mg/L] to screen the tested genotypes for their Fe-toxicity tolerance and to classify them as a sensitive/tolerant category. The evaluation was conducted by a germination study, followed by a polyhouse study on growth, yield and physiochemical performances. Results showed significant variations in Fe²⁺-tolerance across genotypes. Increasing Fe²⁺ level beyond 300 mg/L was detrimental for germination and growth of all the tested genotypes, although germination responses were negatively affected at Fe²⁺ ≥ 300 mg/L. Physiochemical responses in the form of leaf greenness, net photosynthetic rate, membrane stability index and Fe contents in leaf and root were the most representative of Fe²⁺-toxicity-mediated impairments on overall growth and yield. Difference in physiochemical responses was effectively correlated with the contrasting ability of the genotypes on lowering excess Fe²⁺ in tissues. Analysis of average tolerance and stress tolerance index unveiled that the genotypes RD85 and RD31 were the closest to the tolerant check Azucena and the sensitive check IR64, respectively. The unweighted pair group method with arithmetic means clustering revealed three major clusters, with cluster II (four genotypes) being Fe²⁺ tolerant and cluster I (four genotypes) being Fe²⁺ sensitive. Principal component (PC) analysis and genotype by trait-biplot analysis showed that the first two components explained 90.5% of the total variation, with PC1 accounting for 56.6% and PC2 for 33.9% of the total variation. The identified tolerant rice genotypes show potentials for cultivation in Fe²⁺-toxic lowlands for increased productivity. The findings contribute to the present understanding on Fe²⁺-toxicity response and provide a basis for future genotype selection or rice crop improvement programs against Fe²⁺-toxicity.

Key words: iron toxicity, Oryza sativa L., submerged soil, principal component analysis, stress tolerance index

Sheikh Faruk Ahmed, Hayat Ullah, May Zun Aung, Rujira Tisarum, Suriyan Cha-Um, Avishek Datta. Iron Toxicity Tolerance of Rice Genotypes in Relation to Growth, Yield and Physiochemical Characters[J]. Rice Science, 2023, 30(4): 321-334.

Figures/Tables 6

References 62

[1]	Abdi H, Williams L J. 2010. Principal component analysis. WIREs Comp Stat, 2(4): 433-459.
[2]	Ali J, Jewel Z, Mahender A, Anandan A, Hernandez J, Li Z K. 2018. Molecular genetics and breeding for nutrient use efficiency in rice. Int J Mol Sci, 19(6): 1762.
[3]	Asch F, Becker M, Kpongor D S. 2005. A quick and efficient screen for resistance to iron toxicity in lowland rice. J Plant Nutr Soil Sci, 168(6): 764-773.
[4]	Audebert A, Fofana M. 2009. Rice yield gap due to iron toxicity in West Africa. J Agron Crop Sci, 195(1): 66-76.
[5]	Audebert A, Sahrawat K L. 2000. Mechanisms for iron toxicity tolerance in lowland rice. J Plant Nutr, 23(11/12): 1877-1885.
[6]	Bahrami F, Arzani A, Karimi V. 2014. Evaluation of yield-based drought tolerance indices for screening safflower genotypes. Agron J, 106(4): 1219-1224.
[7]	Becker M, Asch F. 2005. Iron toxicity in rice: Conditions and management concepts. J Plant Nutr Soil Sci, 168(4): 558-573.
[8]	Chan-Rodriguez D, Walker E L. 2018. Analysis of yellow striped mutants of Zea mays reveals novel loci contributing to iron deficiency chlorosis. Front Plant Sci, 9: 157. PMID
[9]	Cha-um S, Supaibulwatana K, Kirdmanee C. 2006. Water relation, photosynthetic ability and growth of Thai jasmine rice (Oryza sativa L. ssp. indica cv. KDML 105) to salt stress by application of exogenous glycinebetaine and choline. J Agron Crop Sci, 192(1): 25-36.
[10]	Chérif M, Audebert A, Fofana M, Zouzou M. 2009. Evaluation of iron toxicity on lowland irrigated rice in West Africa. Tropicultura, 27(2): 88-92.
[11]	Ellis R H, Roberts E H. 1981. The quantification of ageing and survival in orthodox seeds. Seed Sci Technol, 9: 373-409.
[12]	Engel K, Asch F, Becker M. 2012. Classification of rice genotypes based on their mechanisms of adaptation to iron toxicity. J Plant Nutr Soil Sci, 175(6): 871-881.
[13]	Fageria N K. 2007. Yield physiology of rice. J Plant Nutr, 30(6): 843-879.
[14]	Fageria N K, Baligar V C, Li Y C. 2008. The role of nutrient efficient plants in improving crop yields in the twenty first century. J Plant Nutr, 31(6): 1121-1157.
[15]	Fernandez G C. 1992. Effective selection criteria for assessing plant stress tolerance. In: Proceeding of the International Symposium on Adaptation of Vegetables and other Food Crops in Temperature and Water Stress. 13-16 Aug 1992, Taiwan, China: 257-270.
[16]	Harahap S M, Ghulamahdi M, Aziz S A, Sutandi A, Miftahudin Dr. 2014. Relationship of ethylene production and aerenchyme formation on oxidation ability and root surfaced-iron (Fe²⁺) accumulation under different iron concentrations and rice genotypes. Int J Appl Sci, 4(1): 186-194.
[17]	Hayat S, Hasan S A, Fariduddin Q, Ahmad A. 2008. Growth of tomato (Lycopersicon esculentum) in response to salicylic acid under water stress. J Plant Interact, 3(4): 297-304.
[18]	Hellal F A, El-Shabrawi H M, Abd El-Hady M, Khatab I A, El-Sayed S A, Abdelly C. 2018. Influence of PEG induced drought stress on molecular and biochemical constituents and seedling growth of Egyptian barley cultivars. J Genet Eng Biotechnol, 16(1): 203-212. PMID
[19]	Hernández-Herrera R M, Santacruz-Ruvalcaba F, Ruiz-López M A, Norrie J, Hernández-Carmona G. 2014. Effect of liquid seaweed extracts on growth of tomato seedlings (Solanum lycopersicum L.). J Appl Phycol, 26(1): 619-628.
[20]	Hussain F, Bronson K F, Yadvinder S, Singh B, Peng S. 2000. Use of chlorophyll meter sufficiency indices for nitrogen management of irrigated rice in Asia. Agron J, 92(5): 875-879.
[21]	Ishimaru Y, Suzuki M, Tsukamoto T, Suzuki K, Nakazono M, Kobayashi T, Wada Y, Watanabe S, Matsuhashi S, Takahashi M, Nakanishi H, Mori S, Nishizawa N K. 2006. Rice plants take up iron as an Fe³⁺-phytosiderophore and as Fe²⁺. Plant J, 45(3): 335-346. PMID
[22]	Jain A, Connolly E L. 2013. Mitochondrial iron transport and homeostasis in plants. Front Plant Sci, 4: 348. PMID
[23]	Kar S, Panda S K. 2020. Iron homeostasis in rice: Deficit and excess. Proc Natl Acad Sci India Sect B Biol Sci, 90(2): 227-235.
[24]	Keita A, Yacouba H, Hayde L G, Schultz B. 2013. A single-season irrigated rice soil presents higher iron toxicity risk in tropical savannah valley bottoms. Open J Soil Sci, 3(7): 314-322.
[25]	Khan F U, Mohammad F. 2016. Application of stress selection indices for assessment of nitrogen tolerance in wheat (Triticum aestivum L.). J Anim Plant Sci, 26(1): 201-210.
[26]	Kirk G. 2004. The biogeochemistry of submerged soils. Chichester, UK: John Wiley & Sons, Ltd.: 304.
[27]	Krohling C A, Eutrópio F J, Bertolazi A A, Dobbss L B, Campostrini E, Dias T, Ramos A C. 2016. Ecophysiology of iron homeostasis in plants. Soil Sci Plant Nutr, 62(1): 39-47.
[28]	Lê S, Josse J, Husson F. 2008. FactoMineR: An R package for multivariate analysis. J Stat Softw, 25: 1-18.
[29]	Lestari A P, Suwarno, Trikoesoemaningtyas, Sopandie D, Aswidinnoor H. 2019. Estimation for stress tolerance indices of rice genotypes in low nitrogen condition. Thai J Agric Sci, 52(4): 180-190.
[30]	Li G J, Kronzucker H J, Shi W M. 2016. Root developmental adaptation to Fe toxicity: Mechanisms and management. Plant Signal Behav, 11(1): e1117722.
[31]	López-Millán A F, Duy D, Philippar K. 2016. Chloroplast iron transport proteins: Function and impact on plant physiology. Front Plant Sci, 7: 178. PMID
[32]	Maguire J D. 1962. Speed of germination: Aid in selection and evaluation for seedling emergence and Vigor. Crop Sci, 2(2): 176-177.
[33]	Mahender A, Swamy B P M, Anandan A, Ali J. 2019. Tolerance of iron-deficient and -toxic soil conditions in rice. Plants, 8(2): 31.
[34]	Matthus E, Wu L B, Ueda Y, Höller S, Becker M, Frei M. 2015. Loci, genes, and mechanisms associated with tolerance to ferrous iron toxicity in rice (Oryza sativa L.). Theor Appl Genet, 128(10): 2085-2098. PMID
[35]	Mohi-Ud-Din M, Hossain M A, Rohman M M, Uddin M N, Haque M S, Ahmed J U, Hossain A, Hassan M M, Mostofa M G. 2021. Multivariate analysis of morpho-physiological traits reveals differential drought tolerance potential of bread wheat genotypes at the seedling stage. Plants, 10(5): 879.
[36]	Müller C, Kuki K N, Pinheiro D T, de Souza L R, Silva A I S, Loureiro M E, Oliva M A, Almeida A M. 2015. Differential physiological responses in rice upon exposure to excess distinct iron forms. Plant Soil, 391(1): 123-138.
[37]	Nugraha Y, Rumanti I A, Guswara A, Ardie S W, Suwarno, Ghulammahdi M, Aswidinnoor H. 2016. Response of selected rice varieties under excess iron condition in media culture at seedling stage. J Pen Pert Tan Pangan, 35(3): 181-190.
[38]	Onaga G, Edema R, Asea G. 2013a. Tolerance of rice germplasm to iron toxicity stress and the relationship between tolerance, Fe²⁺, P and K content in the leaves and roots. Arch Agron Soil Sci, 59(2): 213-229.
[39]	Onaga G, Egdane J, Edema R, Abdelbagi I. 2013b. Morphological and genetic diversity analysis of rice accessions (Oryza sativa L.) differing in iron toxicity tolerance. J Crop Sci Biotechnol, 16(1): 53-62.
[40]	Onaga G, Dramé K N, Ismail A M. 2016. Understanding the regulation of iron nutrition: Can it contribute to improving iron toxicity tolerance in rice? Funct Plant Biol, 43(8): 709-726. PMID
[41]	Onyango D A, Entila F, Dida M M, Ismail A M, Drame K N. 2018. Mechanistic understanding of iron toxicity tolerance in contrasting rice varieties from Africa: 1. Morpho-physiological and biochemical responses. Funct Plant Biol, 46(1): 93-105. PMID
[42]	Pawar S, Pandit E, Mohanty I C, Saha D, Pradhan S K. 2021. Population genetic structure and association mapping for iron toxicity tolerance in rice. PLoS One, 16(3): e0246232.
[43]	Pereira E G, Oliva M A, Rosado-Souza L, Mendes G C, Colares D S, Stopato C H, Almeida A M. 2013. Iron excess affects rice photosynthesis through stomatal and non-stomatal limitations. Plant Sci, 201/202: 81-92.
[44]	Phukunkamkaew S, Tisarum R, Pipatsitee P, Samphumphuang T, Maksup S, Cha-Um S. 2021. Morpho-physiological responses of indica rice (Oryza sativa sub. indica) to aluminum toxicity at seedling stage. Environ Sci Pollut Res Int, 28(23): 29321-29331.
[45]	Quinet M, Vromman D, Clippe A, Bertin P, Lequeux H, Dufey I, Lutts S, Lefèvre I. 2012. Combined transcriptomic and physiological approaches reveal strong differences between short- and long-term response of rice (Oryza sativa) to iron toxicity. Plant Cell Environ, 35(10): 1837-1859.
[46]	Ray D K, Mueller N D, West P C, Foley J A. 2013. Yield trends are insufficient to double global crop production by 2050. PLoS One, 8(6): e66428.
[47]	Rout G R, Sunita S, Das A B, Das S R. 2014. Screening of iron toxicity in rice genotypes on the basis of morphological, physiological and biochemical analysis. J Exp Biol Agric Sci, 2(6): 567-582.
[48]	Rout G R, Sahoo S. 2015. Role of iron in plant growth and metabolism. Rev Agric Sci, 3: 1-24.
[49]	Roy S C, Sharma B D. 2014. Assessment of genetic diversity in rice [Oryza sativa L.] germplasm based on agro-morphology traits and zinc-iron content for crop improvement. Physiol Mol Biol Plants, 20(2): 209-224.
[50]	Santiago-Arenas R, Fanshuri B A, Hadi S N, Ullah H, Datta A. 2020. Nitrogen fertiliser and establishment method affect growth, yield and nitrogen use efficiency of rice under alternate wetting and drying irrigation. Ann Appl Biol, 176(3): 314-327.
[51]	Sikirou M, Saito K, Achigan-Dako E G, Dramé K N, Adam A, Venuprasad R. 2015. Genetic improvement of iron toxicity tolerance in rice-progress, challenges and prospects in West Africa. Plant Prod Sci, 18(4): 423-434.
[52]	Sikirou M, Saito K, Dramé K N, Saidou A, Dieng I, Ahanchédé A, Venuprasad R. 2016. Soil-based screening for iron toxicity tolerance in rice using pots. Plant Prod Sci, 19(4): 489-496.
[53]	Stein R J, Lopes S I G, Fett J P. 2014. Iron toxicity in field- cultivated rice: Contrasting tolerance mechanisms in distinct cultivars. Theor Exp Plant Physiol, 26(2): 135-146.
[54]	Streck E A, Aguiar G A, Facchinello P H K, Perin L, da Silva P U, de Magalhães Júnior A M. 2019. Tolerance and phenotypic analysis of irrigated rice genotypes under iron toxicity. J Exp Agric Int, 31: 1-11.
[55]	Tarantino T B, Barbosa I S, Lima D, Pereira M, Teixeira L S G, Korn M G A. 2017. Microwave-assisted digestion using diluted nitric acid for multi-element determination in rice by ICP OES and ICP-MS. Food Anal Method, 10(4): 1007-1015.
[56]	Tennant D. 1975. A test of a modified line intersect method of estimating root length. J Ecol, 63: 995-1001.
[57]	Tripathi D K, Singh S, Gaur S, Singh S, Yadav V, Liu S L, Singh V P, Sharma S, Srivastava P, Prasad S M, Dubey N K, Chauhan D K, Sahi S. 2018. Acquisition and homeostasis of iron in higher plants and their probable role in abiotic stress tolerance. Front Environ Sci, 5: 86.
[58]	Ullah H, Datta A, Shrestha S, Ud Din S. 2017. The effects of cultivation methods and water regimes on root systems of drought-tolerant (RD6) and drought-sensitive (RD10) rice varieties of Thailand. Arch Agron Soil Sci, 63(9): 1198-1209.
[59]	Ullah H, Giri S, Attia A, Datta A. 2020. Effects of establishment method and water management on yield and water productivity of tropical lowland rice. Exp Agr, 56(3): 331-346.
[60]	Wickham H. 2016. ggplot2: Elegant Graphics for Data Analysis. New York, USA: Springer.
[61]	Wu L B, Shhadi M Y, Gregorio G, Matthus E, Becker M, Frei M. 2014. Genetic and physiological analysis of tolerance to acute iron toxicity in rice. Rice, 7(1): 8.
[62]	Zaid A, Ahmad B, Jaleel H, Wani S H, Hasanuzzaman M. 2020. A critical review on iron toxicity and tolerance in plants: Role of exogenous phytoprotectants. In: Aftab T, Hakeem K R. Plant Micronutrients. Cham, the Switzerland: Springer: 83-99.

Factor	Final germination (%)	Germination energy (%)	Mean germination time (d)	Germination rate index (seed/d)	Root length (cm)	Shoot length (cm)	Seedling vigor index
Genotype (G)
RD31	82.1 ± 1.4 f	64.8 ± 1.4 f	4.8 ± 0.03 a	55.0 ± 1.0 g	2.5 ± 0.1 b	5.3 ± 0.2 d	679.1 ± 23.9 ef
RD41	83.9 ± 1.4 ef	72.2 ± 1.7 de	4.8 ± 0.02 b	58.4 ± 1.0 ef	1.9 ± 0.1 de	5.5 ± 0.1 cd	644.8 ± 20.7 f
RD57	85.4 ± 1.4 de	71.7 ± 1.4 de	4.6 ± 0.03 ef	61.7 ± 1.1 d	2.7 ± 0.2 ab	5.6 ± 0.2 bc	733.0 ± 17.1 cd
RD71	85.4 ± 1.5 de	67.4 ± 1.2 f	4.8 ± 0.03 bc	57.5 ± 1.1 f	2.0 ± 0.1 cd	4.9 ± 0.1 e	603.3 ± 18.1 g
RD77	86.9 ± 1.3 cd	74.1 ± 1.3 cd	4.7 ± 0.01 de	61.3 ± 0.8 d	2.1 ± 0.1 cd	5.8 ± 0.1 b	702.3 ± 17.5 de
RD79	83.6 ± 1.1 ef	70.7 ± 1.3 e	4.7 ± 0.03 cd	58.7 ± 1.0 ef	2.2 ± 0.1 c	5.3 ± 0.1 d	651.2 ± 14.0 f
RD85	91.9 ± 0.9 a	88.0 ± 0.9 a	4.5 ± 0.01 h	73.6 ± 0.6 a	2.7 ± 0.1 ab	6.5 ± 0.1 a	851.0 ± 11.4 a
RD87	88.5 ± 1.1 bc	81.0 ± 1.0 b	4.5 ± 0.02 h	69.4 ± 0.6 b	2.8 ± 0.1 a	5.9 ± 0.1 b	771.6 ± 17.7 b
RD35	89.7 ± 1.0 ab	83.6 ± 1.3 b	4.6 ± 0.03 fg	66.8 ± 0.9 c	1.9 ± 0.1 de	6.3 ± 0.1 a	750.7 ± 12.4 bc
Azucena	85.9 ± 1.4 cde	75.0 ± 1.5 c	4.7 ± 0.02 cd	59.1 ± 0.9 ef	2.8 ± 0.1 ab	5.5 ± 0.1 cd	728.7 ± 15.1 cd
IR64	78.3 ± 1.3 g	73.2 ± 1.3 cde	4.6 ± 0.02 g	60.4 ± 1.0 de	1.8 ± 0.1 e	4.8 ± 0.1 e	554.7 ± 13.2 h
Fe level (Fe, mg/L)
0 (control)	92.9 ± 1.2 a	92.9 ± 1.3 a	4.4 ± 0.01 d	78.8 ± 0.9 a	3.2 ± 0.1 b	7.0 ± 0.1 b	950.5 ± 21.9 b
150	90.6 ± 1.4 b	90.6 ± 1.4 b	4.4 ± 0.01 d	76.5 ± 1.1 b	3.7 ± 0.1 a	7.5 ± 0.1 a	1 014.0 ± 24.2 a
300	88.4 ± 1.1 c	75.9 ± 1.2 c	4.6 ± 0.02 c	62.9 ± 0.8 c	2.2 ± 0.1 c	5.5 ± 0.1 c	684.9 ± 14.1 c
600	84.0 ± 1.1 d	65.5 ± 1.2 d	4.8 ± 0.03 b	53.4 ± 0.8 d	1.4 ± 0.1 d	4.6 ± 0.1 d	516.1 ± 11.6 d
900	72.1 ± 1.4 e	48.6 ± 1.4 e	5.1 ± 0.04 a	38.3 ± 0.9 e	1.1 ± 0.1 e	3.3 ± 0.1 e	321.0 ± 10.6 e
G	**	**	**	**	**	**	**
Fe	**	**	**	**	**	**	**
G × Fe	**	**	**	**	**	**	**

Factor	Final germination (%)	Germination energy (%)	Mean germination time (d)	Germination rate index (seed/d)	Root length (cm)	Shoot length (cm)	Seedling vigor index
Genotype (G)
RD31	82.1 ± 1.4 f	64.8 ± 1.4 f	4.8 ± 0.03 a	55.0 ± 1.0 g	2.5 ± 0.1 b	5.3 ± 0.2 d	679.1 ± 23.9 ef
RD41	83.9 ± 1.4 ef	72.2 ± 1.7 de	4.8 ± 0.02 b	58.4 ± 1.0 ef	1.9 ± 0.1 de	5.5 ± 0.1 cd	644.8 ± 20.7 f
RD57	85.4 ± 1.4 de	71.7 ± 1.4 de	4.6 ± 0.03 ef	61.7 ± 1.1 d	2.7 ± 0.2 ab	5.6 ± 0.2 bc	733.0 ± 17.1 cd
RD71	85.4 ± 1.5 de	67.4 ± 1.2 f	4.8 ± 0.03 bc	57.5 ± 1.1 f	2.0 ± 0.1 cd	4.9 ± 0.1 e	603.3 ± 18.1 g
RD77	86.9 ± 1.3 cd	74.1 ± 1.3 cd	4.7 ± 0.01 de	61.3 ± 0.8 d	2.1 ± 0.1 cd	5.8 ± 0.1 b	702.3 ± 17.5 de
RD79	83.6 ± 1.1 ef	70.7 ± 1.3 e	4.7 ± 0.03 cd	58.7 ± 1.0 ef	2.2 ± 0.1 c	5.3 ± 0.1 d	651.2 ± 14.0 f
RD85	91.9 ± 0.9 a	88.0 ± 0.9 a	4.5 ± 0.01 h	73.6 ± 0.6 a	2.7 ± 0.1 ab	6.5 ± 0.1 a	851.0 ± 11.4 a
RD87	88.5 ± 1.1 bc	81.0 ± 1.0 b	4.5 ± 0.02 h	69.4 ± 0.6 b	2.8 ± 0.1 a	5.9 ± 0.1 b	771.6 ± 17.7 b
RD35	89.7 ± 1.0 ab	83.6 ± 1.3 b	4.6 ± 0.03 fg	66.8 ± 0.9 c	1.9 ± 0.1 de	6.3 ± 0.1 a	750.7 ± 12.4 bc
Azucena	85.9 ± 1.4 cde	75.0 ± 1.5 c	4.7 ± 0.02 cd	59.1 ± 0.9 ef	2.8 ± 0.1 ab	5.5 ± 0.1 cd	728.7 ± 15.1 cd
IR64	78.3 ± 1.3 g	73.2 ± 1.3 cde	4.6 ± 0.02 g	60.4 ± 1.0 de	1.8 ± 0.1 e	4.8 ± 0.1 e	554.7 ± 13.2 h
Fe level (Fe, mg/L)
0 (control)	92.9 ± 1.2 a	92.9 ± 1.3 a	4.4 ± 0.01 d	78.8 ± 0.9 a	3.2 ± 0.1 b	7.0 ± 0.1 b	950.5 ± 21.9 b
150	90.6 ± 1.4 b	90.6 ± 1.4 b	4.4 ± 0.01 d	76.5 ± 1.1 b	3.7 ± 0.1 a	7.5 ± 0.1 a	1 014.0 ± 24.2 a
300	88.4 ± 1.1 c	75.9 ± 1.2 c	4.6 ± 0.02 c	62.9 ± 0.8 c	2.2 ± 0.1 c	5.5 ± 0.1 c	684.9 ± 14.1 c
600	84.0 ± 1.1 d	65.5 ± 1.2 d	4.8 ± 0.03 b	53.4 ± 0.8 d	1.4 ± 0.1 d	4.6 ± 0.1 d	516.1 ± 11.6 d
900	72.1 ± 1.4 e	48.6 ± 1.4 e	5.1 ± 0.04 a	38.3 ± 0.9 e	1.1 ± 0.1 e	3.3 ± 0.1 e	321.0 ± 10.6 e
G	**	**	**	**	**	**	**
Fe	**	**	**	**	**	**	**
G × Fe	**	**	**	**	**	**	**

Factor	Plant height (cm)		Root length (m)		Shoot dry matter (g/plant)	Root dry matter (g/plant)		Tiller number per plant	Panicle number per plant		Filled grain ratio (%)	1000-grain weight (g)		Grain yield (g/plant)
Genotype (G)
RD31	92.1 ± 1.9 bc		128.9 ± 6.4 a		86.5 ± 3.0 bc	13.3 ± 0.5 cd		23.6 ± 0.6 ab	16.6 ± 0.7 ab		78.6 ± 0.2 gh	16.8 ± 0.7 cd		19.1 ± 1.1 c
RD41	90.6 ± 3.6 bc		129.1 ± 6.2 a		71.9 ± 1.8 d	13.4 ± 0.7 cd		19.7 ± 0.5 d	14.1 ± 0.8 cd		81.6 ± 0.1 cde	19.0 ± 0.8 ab		19.4 ± 1.2 c
RD57	93.5 ± 2.0 b		127.2 ± 7.7 a		84.3 ± 1.4 c	12.0 ± 1.2 d		22.4 ± 0.5 bc	16.5 ± 0.8 ab		79.2 ± 0.1 fgh	18.3 ± 0.3 b		18.8 ± 1.0 c
RD71	91.7 ± 1.7 bc		125.4 ± 7.7 a		73.3 ± 1.3 d	13.0 ± 0.5 cd		21.4 ± 0.5 bcd	14.8 ± 0.9 bcd		81.2 ± 0.1 def	19.2 ± 0.7 ab		20.5 ± 0.8 bc
RD77	90.1 ± 2.7 bcd		121.4 ± 6.7 a		69.1 ± 2.3 de	11.6 ± 0.7 d		22.1 ± 0.8 bc	16.4 ± 0.8 ab		78.9 ± 0.2 gh	18.8 ± 0.4 ab		20.6 ± 0.8 bc
RD79	90.9 ± 2.4 bc		121.4 ± 6.8 a		90.1 ± 2.0 b	13.8 ± 0.6 bcd		21.7 ± 0.8 bcd	16.1 ± 1.2 abc		80.3 ± 0.4 efg	18.8 ± 0.4 b		20.9 ± 0.8 bc
RD85	84.8 ± 1.0 d		125.9 ± 4.4 a		68.5 ± 2.1 de	17.2 ± 1.1 a		22.2 ± 0.7 bc	17.1 ± 0.7 a		84.9 ± 0.3 b	20.3 ± 0.5 a		23.5 ± 0.8 a
RD87	87.9 ± 2.8 cd		120.1 ± 6.9 a		73.5 ± 1.8 d	15.9 ± 1.4 ab		21.0 ± 0.7 cd	15.0 ± 1.1 bc		82.9 ± 0.1 bcd	19.5 ± 0.8 ab		21.8 ± 0.5 ab
RD35	88.4 ± 3.4 bcd		128.9 ± 8.0 a		69.9 ± 1.0 de	16.2 ± 0.5 a		23.3 ± 0.8 zb	15.2 ± 0.9 abc		83.6 ± 0.3 bc	18.2 ± 0.5 bc		22.4 ± 0.8 ab
Azucena	129.3 ± 2.7 a		120.3 ± 10.2 a		106.3 ± 1.8 a	15.0 ± 0.6 abc		11.3 ± 0.5 e	7.0 ± 0.3 e		93.7 ± 0.1 a	18.8 ± 0.6 ab		16.4 ± 0.6 d
IR64	76.0 ± 1.6 e		126.7 ± 7.0 a		64.6 ± 4.0 e	16.5 ± 0.9 a		24.7 ± 1.0 a	13.0 ± 1.1 d		78.0 ± 0.2 h	16.5 ± 0.5 d		19.0 ± 1.0 c
Fe level (Fe, mg/L)
0 (control)	92.1 ± 2.2 ab		121.1 ± 8.8 c		80.9 ± 1.6 c	13.7 ± 0.8 c		21.5 ± 0.7 bc	15.5 ± 0.8 b		81.3 ± 0.8 bc	18.8 ± 0.4 c		21.0 ± 0.9 c
150	94.3 ± 2.8 a		134.6 ± 5.6 b		89.6 ± 1.5 b	17.5 ± 0.7 b		22.5 ± 0.7 ab	16.9 ± 0.9 a		83.0 ± 1.2 ab	19.9 ± 0.6 b		23.6 ± 1.2 b
300	94.9 ± 2.7 a		149.7 ± 7.1 a		97.7 ± 2.4 a	21.0 ± 1.0 a		23.3 ± 0.7 a	16.5 ± 1.0 ab		83.2 ± 0.8 a	20.8 ± 0.9 a		25.2 ± 1.3 a
600	91.1 ± 1.6 b		115.2 ± 7.5 c		69.5 ± 2.2 d	11.6 ± 0.9 d		20.6 ± 0.6 c	13.2 ± 0.8 c		81.9 ± 1.0 c	17.7 ± 0.4 d		18.8 ± 0.4 d
900	89.1 ± 2.3 b		104.6 ± 6.5 d		52.3 ± 2.5 e	7.9 ± 0.5 e		18.2 ± 0.6 d	11.3 ± 0.8 d		81.0 ± 0.9 c	15.6 ± 0.5 e		12.5 ± 0.5 e
G	**		ns		**	**		**	**		**	**		**
Fe	**		**		**	**		**	**		**	**		**
G × Fe	ns		ns		**	**		*	*		**	**		**
Factor		SPAD value		Net photosynthetic rate [μmol/(m²∙s)]			Membrane stability index (%)			Leaf Fe content (mg/g)			Root Fe content (mg/g)
Genotype (G)
RD31		36.9 ± 0.4 cd		18.6 ± 0.6 b			72.8 ± 0.5 cd			7.2 ± 0.2 b			11.8 ± 0.4 b
RD41		37.8 ± 0.5 abcd		18.2 ± 0.7 b			75.2 ± 0.5 abcd			3.7 ± 0.1 f			10.9 ± 0.4 f
RD57		38.3 ± 0.3 abc		18.8 ± 1.0 b			77.1 ± 0.5 abc			5.7 ± 0.1 e			11.0 ± 0.2 d
RD71		38.1 ± 0.4 abc		19.6 ± 0.8 b			75.3 ± 0.6 abcd			5.3 ± 0.1 d			11.4 ± 0.3 e
RD77		35.7 ± 0.4 d		19.3 ± 0.6 b			74.5 ± 0.5 bcd			6.2 ± 0.1 c			11.6 ± 0.5 c
RD79		39.1 ± 0.2 abc		19.4 ± 0.8 b			77.2 ± 0.5 abc			3.9 ± 0.1 f			11.0 ± 0.3 e
RD85		39.2 ± 0.5 abc		23.0 ± 0.9 a			80.4 ± 0.2 ab			2.3 ± 0.1 h			10.1 ± 0.3 i
RD87		40.1 ± 0.3 a		22.4 ± 1.2 a			78.5 ± 0.4 abc			3.1 ± 0.1 g			10.6 ± 0.4 g
RD35		39.3 ± 0.5 ab		21.8 ± 0.8 a			78.4 ± 0.4 abc			2.6 ± 0.1 h			10.4 ± 0.2 h
Azucena		39.2 ± 0.6 ab		19.8 ± 0.7 b			81.3 ± 0.6 a			2.5 ± 0.1 h			9.9 ± 0.5 j
IR64		37.6 ± 0.5 bcd		19.2 ± 0.8 b			70.0 ± 0.4 d			8.7 ± 0.3 a			12.3 ± 0.5 a
Fe level (Fe, mg/L)
0 (control)		38.4 ± 0.4 bc		20.5 ± 0.7 c			84.1 ± 0.4 a			0.7 ± 0.0 e			4.1 ± 0.5 e
150		39.3 ± 0.4 ab		22.4 ± 0.5 b			83.9 ± 0.5 a			1.2 ± 0.0 d			8.0 ± 0.2 d
300		40.1 ± 0.4 a		25.0 ± 1.2 a			77.9 ± 0.4 b			2.0 ± 0.1 c			10.8 ± 0.2 c
600		37.5 ± 0.4 c		18.4 ± 0.5 d			71.4 ± 0.5 c			6.5 ± 0.1 b			13.3 ± 0.2 b
900		36.1 ± 0.4 d		13.7 ± 1.1 e			64.7 ± 0.6 d			12.8 ± 0.4 a			18.7 ± 0.5 a
G		**		**			**			**			**
Fe		**		**			**			**			**
G × Fe		**		**			**			**			**

Factor	Plant height (cm)		Root length (m)		Shoot dry matter (g/plant)	Root dry matter (g/plant)		Tiller number per plant	Panicle number per plant		Filled grain ratio (%)	1000-grain weight (g)		Grain yield (g/plant)
Genotype (G)
RD31	92.1 ± 1.9 bc		128.9 ± 6.4 a		86.5 ± 3.0 bc	13.3 ± 0.5 cd		23.6 ± 0.6 ab	16.6 ± 0.7 ab		78.6 ± 0.2 gh	16.8 ± 0.7 cd		19.1 ± 1.1 c
RD41	90.6 ± 3.6 bc		129.1 ± 6.2 a		71.9 ± 1.8 d	13.4 ± 0.7 cd		19.7 ± 0.5 d	14.1 ± 0.8 cd		81.6 ± 0.1 cde	19.0 ± 0.8 ab		19.4 ± 1.2 c
RD57	93.5 ± 2.0 b		127.2 ± 7.7 a		84.3 ± 1.4 c	12.0 ± 1.2 d		22.4 ± 0.5 bc	16.5 ± 0.8 ab		79.2 ± 0.1 fgh	18.3 ± 0.3 b		18.8 ± 1.0 c
RD71	91.7 ± 1.7 bc		125.4 ± 7.7 a		73.3 ± 1.3 d	13.0 ± 0.5 cd		21.4 ± 0.5 bcd	14.8 ± 0.9 bcd		81.2 ± 0.1 def	19.2 ± 0.7 ab		20.5 ± 0.8 bc
RD77	90.1 ± 2.7 bcd		121.4 ± 6.7 a		69.1 ± 2.3 de	11.6 ± 0.7 d		22.1 ± 0.8 bc	16.4 ± 0.8 ab		78.9 ± 0.2 gh	18.8 ± 0.4 ab		20.6 ± 0.8 bc
RD79	90.9 ± 2.4 bc		121.4 ± 6.8 a		90.1 ± 2.0 b	13.8 ± 0.6 bcd		21.7 ± 0.8 bcd	16.1 ± 1.2 abc		80.3 ± 0.4 efg	18.8 ± 0.4 b		20.9 ± 0.8 bc
RD85	84.8 ± 1.0 d		125.9 ± 4.4 a		68.5 ± 2.1 de	17.2 ± 1.1 a		22.2 ± 0.7 bc	17.1 ± 0.7 a		84.9 ± 0.3 b	20.3 ± 0.5 a		23.5 ± 0.8 a
RD87	87.9 ± 2.8 cd		120.1 ± 6.9 a		73.5 ± 1.8 d	15.9 ± 1.4 ab		21.0 ± 0.7 cd	15.0 ± 1.1 bc		82.9 ± 0.1 bcd	19.5 ± 0.8 ab		21.8 ± 0.5 ab
RD35	88.4 ± 3.4 bcd		128.9 ± 8.0 a		69.9 ± 1.0 de	16.2 ± 0.5 a		23.3 ± 0.8 zb	15.2 ± 0.9 abc		83.6 ± 0.3 bc	18.2 ± 0.5 bc		22.4 ± 0.8 ab
Azucena	129.3 ± 2.7 a		120.3 ± 10.2 a		106.3 ± 1.8 a	15.0 ± 0.6 abc		11.3 ± 0.5 e	7.0 ± 0.3 e		93.7 ± 0.1 a	18.8 ± 0.6 ab		16.4 ± 0.6 d
IR64	76.0 ± 1.6 e		126.7 ± 7.0 a		64.6 ± 4.0 e	16.5 ± 0.9 a		24.7 ± 1.0 a	13.0 ± 1.1 d		78.0 ± 0.2 h	16.5 ± 0.5 d		19.0 ± 1.0 c
Fe level (Fe, mg/L)
0 (control)	92.1 ± 2.2 ab		121.1 ± 8.8 c		80.9 ± 1.6 c	13.7 ± 0.8 c		21.5 ± 0.7 bc	15.5 ± 0.8 b		81.3 ± 0.8 bc	18.8 ± 0.4 c		21.0 ± 0.9 c
150	94.3 ± 2.8 a		134.6 ± 5.6 b		89.6 ± 1.5 b	17.5 ± 0.7 b		22.5 ± 0.7 ab	16.9 ± 0.9 a		83.0 ± 1.2 ab	19.9 ± 0.6 b		23.6 ± 1.2 b
300	94.9 ± 2.7 a		149.7 ± 7.1 a		97.7 ± 2.4 a	21.0 ± 1.0 a		23.3 ± 0.7 a	16.5 ± 1.0 ab		83.2 ± 0.8 a	20.8 ± 0.9 a		25.2 ± 1.3 a
600	91.1 ± 1.6 b		115.2 ± 7.5 c		69.5 ± 2.2 d	11.6 ± 0.9 d		20.6 ± 0.6 c	13.2 ± 0.8 c		81.9 ± 1.0 c	17.7 ± 0.4 d		18.8 ± 0.4 d
900	89.1 ± 2.3 b		104.6 ± 6.5 d		52.3 ± 2.5 e	7.9 ± 0.5 e		18.2 ± 0.6 d	11.3 ± 0.8 d		81.0 ± 0.9 c	15.6 ± 0.5 e		12.5 ± 0.5 e
G	**		ns		**	**		**	**		**	**		**
Fe	**		**		**	**		**	**		**	**		**
G × Fe	ns		ns		**	**		*	*		**	**		**
Factor		SPAD value		Net photosynthetic rate [μmol/(m²∙s)]			Membrane stability index (%)			Leaf Fe content (mg/g)			Root Fe content (mg/g)
Genotype (G)
RD31		36.9 ± 0.4 cd		18.6 ± 0.6 b			72.8 ± 0.5 cd			7.2 ± 0.2 b			11.8 ± 0.4 b
RD41		37.8 ± 0.5 abcd		18.2 ± 0.7 b			75.2 ± 0.5 abcd			3.7 ± 0.1 f			10.9 ± 0.4 f
RD57		38.3 ± 0.3 abc		18.8 ± 1.0 b			77.1 ± 0.5 abc			5.7 ± 0.1 e			11.0 ± 0.2 d
RD71		38.1 ± 0.4 abc		19.6 ± 0.8 b			75.3 ± 0.6 abcd			5.3 ± 0.1 d			11.4 ± 0.3 e
RD77		35.7 ± 0.4 d		19.3 ± 0.6 b			74.5 ± 0.5 bcd			6.2 ± 0.1 c			11.6 ± 0.5 c
RD79		39.1 ± 0.2 abc		19.4 ± 0.8 b			77.2 ± 0.5 abc			3.9 ± 0.1 f			11.0 ± 0.3 e
RD85		39.2 ± 0.5 abc		23.0 ± 0.9 a			80.4 ± 0.2 ab			2.3 ± 0.1 h			10.1 ± 0.3 i
RD87		40.1 ± 0.3 a		22.4 ± 1.2 a			78.5 ± 0.4 abc			3.1 ± 0.1 g			10.6 ± 0.4 g
RD35		39.3 ± 0.5 ab		21.8 ± 0.8 a			78.4 ± 0.4 abc			2.6 ± 0.1 h			10.4 ± 0.2 h
Azucena		39.2 ± 0.6 ab		19.8 ± 0.7 b			81.3 ± 0.6 a			2.5 ± 0.1 h			9.9 ± 0.5 j
IR64		37.6 ± 0.5 bcd		19.2 ± 0.8 b			70.0 ± 0.4 d			8.7 ± 0.3 a			12.3 ± 0.5 a
Fe level (Fe, mg/L)
0 (control)		38.4 ± 0.4 bc		20.5 ± 0.7 c			84.1 ± 0.4 a			0.7 ± 0.0 e			4.1 ± 0.5 e
150		39.3 ± 0.4 ab		22.4 ± 0.5 b			83.9 ± 0.5 a			1.2 ± 0.0 d			8.0 ± 0.2 d
300		40.1 ± 0.4 a		25.0 ± 1.2 a			77.9 ± 0.4 b			2.0 ± 0.1 c			10.8 ± 0.2 c
600		37.5 ± 0.4 c		18.4 ± 0.5 d			71.4 ± 0.5 c			6.5 ± 0.1 b			13.3 ± 0.2 b
900		36.1 ± 0.4 d		13.7 ± 1.1 e			64.7 ± 0.6 d			12.8 ± 0.4 a			18.7 ± 0.5 a
G		**		**			**			**			**
Fe		**		**			**			**			**
G × Fe		**		**			**			**			**

Genotype	Tolerance (TOL)					Stress tolerance index (STI)
Genotype	150 mg/L	300 mg/L	600 mg/L	900 mg/L	Mean^#	150 mg/L	300 mg/L	600 mg/L	900 mg/L	Mean^#
RD31	-2.92 ± 0.26 g	-5.24 ± 0.69 i	1.83 ± 0.62 e	10.16 ± 1.75 b	5.99 ± 1.19 c	1.00 ± 0.01 b	1.03 ± 0.01 d	0.83 ± 0.01 g	0.66 ± 0.01 g	0.75 ± 0.01 f
RD41	-3.79 ± 0.15 i	-5.32 ± 0.29 j	1.31 ± 0.38 f	7.23 ± 1.08 i	4.27 ± 0.78 h	1.04 ± 0.00 a	1.10 ± 0.01 a	0.85 ± 0.01 f	0.81 ± 0.01 c	0.83 ± 0.01 d
RD57	-4.10 ± 0.51 j	-5.68 ± 0.61 k	2.73 ± 0.68 b	8.34 ± 1.13 e	5.54 ± 0.91 d	1.01 ± 0.02 b	1.11 ± 0.00 a	0.88 ± 0.02 de	0.77 ± 0.01 e	0.83 ± 0.02 d
RD71	-2.66 ± 0.19 e	-4.88 ± 0.25 f	2.32 ± 0.60 c	8.16 ± 1.24 g	5.24 ± 0.92 f	1.01 ± 0.01 b	1.08 ± 0.01 c	0.87 ± 0.00 ef	0.77 ± 0.02 e	0.82 ± 0.01 d
RD77	-2.19 ± 0.11 c	-4.91 ± 0.82 g	2.29 ± 0.81 d	8.32 ± 1.38 f	5.30 ± 1.10 e	1.01 ± 0.01 b	1.10 ± 0.02 ab	0.85 ± 0.01 f	0.75 ± 0.01 f	0.80 ± 0.01 e
RD79	-3.04 ± 0.28 h	-5.01 ± 0.26 h	2.28 ± 0.75 d	9.77 ± 1.13 c	6.03 ± 0.94 b	1.02 ± 0.01 ab	1.10 ± 0.00 ab	0.90 ± 0.01 d	0.79 ± 0.01 cd	0.84 ± 0.01 c
RD85	-2.46 ± 0.12 d	-3.79 ± 0.82 b	1.21 ± 0.39 g	6.93 ± 1.20 j	4.07 ± 0.80 j	1.01 ± 0.03 b	1.12 ± 0.02 a	0.94 ± 0.02 ab	0.83 ± 0.02 b	0.88 ± 0.02 b
RD87	-1.03 ± 0.09 a	-4.06 ± 0.71 d	0.86 ± 0.57 h	9.48 ± 1.79 d	5.17 ± 1.18 g	1.01 ± 0.02 b	1.08 ± 0.01 bc	0.91 ± 0.01 c	0.78 ± 0.02 de	0.85 ± 0.02 c
RD35	-2.77 ± 0.14 f	-4.29 ± 0.95 e	0.73 ± 0.90 i	7.78 ± 1.67 h	4.26 ± 1.29 i	1.01 ± 0.01 b	1.11 ± 0.00 a	0.92 ± 0.01 bc	0.83 ± 0.01 b	0.87 ± 0.01 b
Azucena	-1.19 ± 0.17 b	-3.87 ± 0.43 c	0.45 ± 0.45 j	4.36 ± 0.98 k	2.40 ± 0.72 k	1.02 ± 0.01 ab	1.10 ± 0.00 ab	0.95 ± 0.02 a	0.85 ± 0.02 a	0.90 ± 0.02 a
IR64	-3.02 ± 0.35 h	1.16 ± 0.67 a	8.15 ± 1.79 a	12.95 ± 1.34 a	10.55 ± 1.57 a	1.00 ± 0.01 b	0.91 ± 0.01 e	0.70 ± 0.01 h	0.58 ± 0.01 h	0.64 ± 0.01 g
